EMERGENCY STOP

Familiarize yourself with the emergency stop procedures and the location of the Emergency Stop buttons of the XP1 before use. Emergency Stop buttons are located on each side of the XP1. When pressed, all four motors controlling the cables will immediately release tension, and the motorized Adjustable Rack Arms will stop.

To reset, twist the Emergency Stop button 90º to the right (it will slightly pop outward) before pressing Restart.

WARNING: DO NOT push the Emergency Stop button when restarting the device.

EMERGENCY BRAKE RELEASE

Familiarize yourself with the Emergency Release pull knob located on the back panel of the XP1. This knob is to be used when the Adjustable Rack Arms must be moved in an emergency situation and the buttons are not functional, or the emergency stop has been pressed. Pulling this knob will cause the Adjustable Rack Arms to slowly fall under their own weight and allow the rack to be manually lifted or pushed down.

After the rack has been moved and the system is ready for use again, push the knob back to its original position. The system must be power cycled for proper operation.
