At OxeFit, it is our goal to make your installation as seamless as possible. To achieve this goal, we require professional installation of your new XS1.
ELECTRICAL OUTLET REQUIREMENTS
The XS1 requires a standard (USA: 120 VAC, 60 Hz), grounded, three-pronged outlet. If your XS1 requires an extension cord, ensure it is rated for at least 12A. Failure to provide these electrical requirements may void your warranty.
INTERNET REQUIREMENTS
The XS1 requires a strong, continuous connection to wireless internet in order to access the advanced features and programs on the device. The XS1 operates best when connected to a 5GHz WiFi network.
You can connect to the internet using WiFi that has a minimum download speed of 15 MBs and a minimum upload speed of 5 MBs, but higher speeds are recommended.
The XS1 only supports WPA2 encryption. We do not recommend the use of WiFi extenders as these devices can result in significantly slower internet speeds. If the WiFi signal is not strong in the planned XS1 location, we recommend using a mesh network to improve the coverage.
NOTE: The XS1 does not support the use of Eero routers and a few others. Please contact support@oxefit.com if you experience any difficulty with your WiFi connection.
LOCATION REQUIREMENTS
The XS1 requires at least 4 inches of space behind the unit. The entire setup space should be at least 6’ x 8.5’.
ENVIRONMENTAL REQUIREMENTS
Due to the sensitivity of the electronics, the XS1 system must be installed in a climate-controlled environment that meets the conditions specified below. The XS1 cannot be installed outdoors and the warranty does not cover devices that are placed outdoors or in locations that do not comply with OxeFit's location and operating environment requirements.
OPERATING RELATIVE HUMIDITY (RH)
20% to 70% non-condensing
OPERATING TEMPERATURE
50°F to 85°F (10°C to 30°C)
STORAGE TEMPERATURE
-13°F to 113°F (-25°C to 45°C)
