The OxeDot is a wireless control device that can load and unload the weight during training on the XS1.
Instead of pressing the “LOAD” and “UNLOAD” button on the screen, clicking the OxeDot will automatically perform these tasks for you.
OxeDot can be attached to any OxeFit accessory and should be positioned where it can easily be pressed during an exercise set.
HOW TO USE
- Press and hold the OxeDot for at least one second (long press) to LOAD the weight when ready to begin a set.
- Press the button again (short press) to UNLOAD the weight when set has been complete.
CONNECTING
- Click OxeDot to “wake” before each training session and allow a few seconds for XS1 to detect its bluetooth signal.
- If OxeDot has previously been connected to XS1, it should reconnect automatically.
- If OxeDot is being connected to XS1 for the first time, it will appear in the Bluetooth Menu under the SCANNED list. When OxeDot appears here, select CONNECT to pair it with XS1.
ADDITIONAL NOTES
- A blinking blue light indicates when an OxeDot is in pairing mode.
- OxeDot will appear in the bluetooth menu labeled by its four-digit ID code.
- Up to three OxeDots can be paired to XS1 at a time.
- To preserve battery life, OxeDots will disconnect when not in use. Click each OxeDot to wake it from sleep mode as needed and allow a few seconds for it to connect.
- Always verify OxeDot connection status before use. When you exit the bluetooth menu, the toolbar will display a number next to the OxeDot icon to indicate how many units are currently paired.
- If there is no light when you press the OxeDot, see CHANGE OXEDOT BATTERY article.
For additional OxeDot or bluetooth information, see XS1 Bluetooth Settings article.
