CLEANING
Keeping your OxeFit XP1 unit(s) clean is essential for preventative maintenance and maintaining the overall aesthetics of your equipment and accessories. Proper care and cleaning will extend the life of your equipment and reduce premature aging and wear.
CAUTION: Always power off and unplug the XP1 before cleaning.
- Barbell should be wiped down after each use and cleaned daily with a mild soap and water mix or an approved antibacterial cleaner.
- Hand grips should be cleaned daily with a mild soap and water mix or a non-abrasive, gentle, and antibacterial cleaner.
- If the bench was used for a workout, upholstery on the bench pads should be cleaned daily with a mild soap and water mix or a non-abrasive, gentle antibacterial cleaner.
- The main frame should be cleaned weekly with a mild soap and water mix and dampened cloth or a gentle antibacterial cleaner to remove all dust and accumulated contaminants.
NOTE: DO NOT use cleaners that contain solvents, alcohol, or abrasives.
DISPLAY MAINTENANCE
Moisture on or near the touchscreen should be avoided. Wipe the screen gently with a clean, soft, and dry cloth.
SOFTWARE MAINTENANCE
Ensure your device is connected to the internet when updating the XP1 software.
PREVENTATIVE MAINTENANCE
Preventative maintenance is crucial for maintaining the function and safety of the XP1. For commercial consumers, your facility must follow written guidelines for preventative maintenance and keep written or digital records of the maintenance performed on the equipment.
Visual inspections of your OxeFit XP1 unit(s) will ensure a safe environment and alert you of any issues that may require maintenance prior to equipment failure. Thorough visual inspections are a critical component of the long-term care of your XP1. Contact OxeFit Support immediately for replacement parts.
In addition to the following preventive maintenance, please keep all open beverages away from the XP1 to ensure proper maintenance and safe usage of your equipment.
DAILY MAINTENANCE
Verify that the Adjustable Rack Arms can be raised and lowered. As the rack moves, listen for unusual sounds, such as squeaks and grinding sounds. Report any issues to support immediately.
Make sure that each adjustment pin inserts completely into each position. Always engage the Safety Rack Posts when exercises are performed.
Inspect carabiners to verify that the latch is properly working and the plastic handle has no damage.
WEEKLY MAINTENANCE
Cables should be inspected weekly for damages, including fraying, abrasion, signs of wear, twisting, or excessive rubbing.
Ensure proper maintenance of your device, cables, motor timing, and motor calibration by performing the following procedure once a week:
1. Power down the XP1 using the power switch located on the back of the device. NOTE: Your XP1 may have a power switch located at the bottom of the back panel or a breaker-style power switch located slightly higher. Please see How do I turn off the XP1? for more information.
2. With the cables attached to the barbell, extend the cables to their full extension (total cable length exiting the system should be about 15 feet) towards the front of the device.
3. Inspect the cables for wear, abrasion, and fraying before slowly releasing the cables.
4. Power the device back on before pressing Initialize to allow the motors to wind the cables slowly.
NOTE: This procedure will prompt a Problem Detected. However, this is not a cause for concern in this instance.
5. When the cables are fully spooled and the clips have reached a hard stop, press Restart to allow your XP1 to initialize properly.
If you notice any signs of issues, including wear, abrasion, and/or fraying, discontinue using the XP1 and contact support immediately.
MONTHLY MAINTENANCE
Inspect all accessories for wear or damage and replace them as needed.
Inspect upholstery for wear or damage and replace it as needed.
Inspect pulleys for integrity, cracking, or rubbing leading to excessive wear. Any incident of wear should elicit immediate replacement of the damaged pulley.
