The XS1 supports bluetooth pairing for heart rate monitors (HRM) that use a standard heart rate protocol to broadcast via bluetooth connection. When paired, the XS1 screen will display your current heart rate in beats per minute (BPM) during active training.
The following HRM devices have been verified for compatibility:
- Wahoo TICKR HRM Chest Strap
- Myzone MZ-3 HRM
- COOSPO HRM Armband HW807
- Garmin 010-12883-00 Dual HRM
- Garmin 165 HRM
- Garmin HRM Pro Plus
- Polar Chest Strap HRM
HRM Pairing
- Place HRM device in broadcast mode
- Tap the dropdown menu in the top right corner of your XS1 screen and select Bluetooth
- Allow up to 60 seconds for your HRM to become visible in Bluetooth Menu *
- Menu includes three statuses: CONNECTED SAVED SCANNED
- When HRM appears in the SCANNED list, select Connect to pair it
- HRM device may jump to the SAVED list momentarily during pairing
- It will move to the CONNECTED list when successfully paired
- The toolbar will display the HRM icon to indicate when a device is paired
Additional Notes
*If HRM does not appear after 60 seconds, tap Refresh and wait an additional 60 seconds. If issue persists, exit Bluetooth Menu and reopen it to reattempt connection.
Once an HRM device is successfully paired, it will be remembered in the SAVED list and will attempt to connect automatically anytime the same user profile is in use.
Only one HRM device can be connected at a time. If you want to connect a different HRM device, you must select Forget to disassociate the one currently in use first, and then proceed to select the new one from the SCANNED list.
For additional information and troubleshooting, see XS1 Bluetooth Settings article.
Contact support if you experience ongoing issues to pair supported devices.
